Product Description

Video compression H 265 Plus H 265 H 264 plus H 264
Analog video input 32 ch BNC interface 1 0 Vp p 75 supporting coaxitron connection
HDTVI input 4 MP 3 MP 1080p30 1080p25 720p60 720p50 720p30 720p25 Note The 3 MP signal input is only available for channel 1 2 3 4
AHD input 4 MP 1080p25 1080p30 720p25 720p30
HDCVI input 1080p25 1080p30 720p25 720p30
CVBS input PAL NTSC
IP video input 2 ch Up to 4 MP resolution Supports H 265 plus H 265 H 264 plus H 264 IP cameras
Audio compression G711u
Audio input 1ch RCA 2 0 Vp p 1 K

CVBS output 1ch BNC 1 0 Vp p 75 resolution PAL 704 x 576 NTSC 704 x 480
HDMI/VGA output VGA 1ch 1920 x 1080 60Hz 1280 x 1024 60Hz 1280 x 720 60Hz 1024 x 768 60Hz HDMI 1ch 4K 3840 x 2160 30Hz 2K 2560 x 1440 60Hz 1920 x 1080 60Hz 1280 x 1024 60Hz 1280 x 720 60Hz 1024 x 768 60Hz
Encoding resolution When 1080p Lite mode not enabled 4 MP lite 3 MP 1080p 720p VGA WD1 4CIF CIF When 1080p Lite mode enabled 4 MP lite 3 MP 1080p lite 720p lite VGA WD1 4CIF CIF
Frame rate Main stream When 1080p Lite mode not enabled For 4 MP stream access 4 MP lite 15fps 1080p lite 720p WD1 4CIF VGA CIF 25fps P 30fps N For 3 MP stream access 3 MP 1080p 720p VGA WD1 4CIF CIF 15fps For 1080p stream access 1080p 720p 15fps VGA WD1 4CIF CIF 25fps P 30fps N For 720p stream access 720p VGA WD1 4CIF CIF 25fps P 30fps N When 1080p Lite mode enabled 4 MP lite 3 MP 15fps 1080p lite 720p lite VGA WD1 4CIF CIF 25fps P 30fps N Sub stream WD1 4CIF 12fps CIF 25fps P 30fps N
Video bit rate 32 Kbps to 6 Mbps
Audio output 1ch RCA Linear 1 K
Audio bit rate 64 Kbps
Dual stream Support
Stream type Video Video and Audio
Synchronous playback 16ch
Network management
- USB interface Front panel 1 x USB 2 0 Rear panel 1 x USB 3 0

Serial interface RS 485 half duplex
