DAHUA 2 MP IP PTZ CCTV CAMERA
Product Details:
DAHUA 2 MP IP PTZ CCTV CAMERA Price And Quantity
- 500 INR/Piece
- 100.00 - 1000.00 INR/Piece
- 1 Piece
Product Description
CameraImage Sensor 1 2 8 INCH CMOS
Pixel 2MP
Max Resolution 1920 H × 1080 V
ROM 128 MB
RAM 256 MB
Electronic Shutter Speed 1 1 s 1 30000 s
Scanning System Progressive
Color 0 05 Lux F1 5
Min Illumination B W 0 005 Lux F1 5
0Lux IR or laser on
Illumination Distance 100 m 328 08 ft
Illuminator On Off Control Zoom Prio Manual SmartIR Off
Illuminator Number 4
Lens
Focal Length 5 mm 80 mm
Max Aperture F1 5 F2 7
Field of View H 57 7 4 5 V 32 7 2 6 D 65 2 5 2
Optical Zoom 16 x
Focus Control Auto Semi Auto Manual
Close Focus Distance 0 1 m 0 5 m 0 33 ft 1 64 ft
Iris Control Auto Manual
Detect Observe Recognize Identify
DORI Distance 1343 m 4406 17 ft 530 m 1738 85 ft 268 m 879 27 ft 134 m 439 63 ft
PTZ
Pan Tilt Range Pan 0 360 Tilt 15 plus 90
Manual Control Speed Pan 0 1 s 200 s Tilt 0 1 s120 s
Preset Speed Pan 240 s Tilt 200 s
Presets 300
Tour 8 up to 32 presets per tour
Pattern 5
Scan 5
Speed Adjustment Support
Power off Memory Support
Idle Motion Preset Tour Pattern Scanning
Protocol DH SD
Pelco P D auto recognition
General Intelligence
Event Trigger Motion detection video tampering scene changing network disconnection IP address conflict illegal access and storage anomaly
IVS Tripwire intrusion object abandoned missing
Video
Compression H 265 H 264 Baseline Profile H 264 Main Profile H 264 High Profile
Streaming Capability 3 streams
Resolution 1080P 1920 × 1080 960P 1280 × 960 720P 1280 × 720
Main stream 1080P 720P 1 25 30 fps
Frame Rate Sub stream 1 D1 CIF 1 25 30 fps
Sub stream 2 720P D1 CIF 1 25 30 fps
Bit Rate Control Variable Constant
H 264 1792 Kbps 8192 Kbps
Bit Rate H 265 768 Kbps 4608 Kbps
Day and Night Auto ICR Color B W
BLC Support
WDR DWDR
HLC Support
White Balance Auto Indoor Outdoor Tracking Manual Sodium lamp Natural Street lamp
Gain Control Auto Manual
Noise Reduction 2D 3D
Motion Detection Support
Region of Interest RoI Support
Image Stabilization EIS Electronic
Defog Electronic
Digital Zoom 16X
Flip 180
Privacy Masking Up to 24 areas
Audio
Compression G 711a G 711Mu G 726 AAC G7221 G726 G729 MP2L2
Network
Ethernet RJ 45 10 100Base T
Protocol IPv4 IPv6 HTTP HTTPS 802 1x Qos FTP SMTP UPnP SNMP DNS DDNS NTP RTSP RTP TCP UDP IGMP ICMP DHCP PPPoE ARP SNMPv1 v2c v3 MIB 2 RTCP RTMP
Interoperability ONVIF Profile S AND G CGI
Streaming Method Unicast Multicast
User Host 20 total bandwidth 48 MB
Storage FTP Micro SD card 256 GB NAS
Browser IE7 and later versions
Chrome 42 and earlier versions
Firefox 52 and earlier versions
Safari
Management Software Smart PSS DSS DMSS Easy4ip IVSS
Mobile Phone IOS Android
Certification
Certifications CE EN55032 EN55024 EN50130 4
FCC Part15 subpartB ANSI C63 4 2014
UL UL62368 1 CAN CSA C222 No 62368 1
Port
Audio Input 1 LINE IN bare wire1 LINE IN bare wire
Audio Output 1 LINE OUT bare wire
Alarm I O 2 1
Power
Power Supply DC 12V/5A 10 percent
Power Consumption 6 1W
17W IR light on
Environment
Operating Temperature 40 C to 70 C 40 F to 158 F
Operating Humidity 95 percent RH
Protection IP66 TVS 6000V lightning protection surge protection
Structure
Dimensions 295 mm × 160 mm 11 61 × 6 30
Net Weight 3 0 kg 6 61 lb
Gross Weight 4 4 kg 9 70 lb
